DataSheet

50HZ

60HZ

　 GOVOX-U 322
Discharge Outlet 80 mm (3")
Shaft Speed 2850 rpm
Rated Output 2.2 kW (3 HP)
Rated Head 12 m (39')
Rated Flow 6 L/s(95 gpm)
Max Head 17 m (56')
Max Flow 14.2 L/s (224 gpm)
Solid Passage 55 mm (2.2")
Diameter 366 mm (14.4")
Height 660 mm (26")
Weight 40 kg (88 lbs)
　 GOVOX-U 322
Discharge Outlet 80 mm (3")
Shaft Speed 3450 rpm
Rated Output 2.2 kW (3 HP)
Rated Head 12 m (39')
Rated Flow 6 L/s (95 gpm)
Max Head 17 m (56')
Max Flow 14.2 L/s (225 gpm)
Solid Passage 55 mm (2.2")
Diameter 366 mm (14.4")
Height 660 mm (26")
Weight 40 kg (88 lbs)
Download File
Product Catalogue 50 Hz 60 Hz
GOVOX-U 322/337 50 Hz 60 Hz
