DataSheet

50HZ

60HZ

　 TITAN 475
Discharge Outlet 100 mm (4")
Shaft Speed 1450 rpm
Rated Output 7.5 kW (10 HP)
Rated Head 14 m (46')
Rated Flow 20 L/s (317 gpm)
Max Head 18.5 m (61')
Max Flow 41.3 L/s (655 gpm)
Solid Passage 25 mm (1")
Diameter 412 mm (16.2")
Height 826 mm (32.5")
Weight 129 kg (284 lbs)
　 TITAN 475
Discharge Outlet 100 mm (4")
Shaft Speed 1750 rpm
Rated Output 7.5 kW (10 HP)
Rated Head 14 m (46')
Rated Flow 20 L/s (317 gpm)
Max Head 18.5 m (61')
Max Flow 41.3 L/s (655 gpm)
Solid Passage 25 mm (1")
Diameter 412 mm (16.2")
Height 826 mm (32.5")
Weight 129 kg (284 lbs)
