- PRORIL

GOVOX 8

GOVOX series pumps feature a less impeller wear and longer pump life by a vortex flow that allows fibrous materials and solid matters to be pumped out without obstruction.

DataSheet

50Hz

	GOVOX 208	GOVOX 308
Discharge Outlet	50 mm (2")	80 mm (3")
Shaft Speed	2850 rpm	2850 rpm
Rated Output	0.75 kW (1 HP)	0.75 kW (1 HP)
Rated Head	8 m (26')	6 m (20')
Rated Flow	3 L/s (48 gpm)	4.2 L/s (66 gpm)
Max Head	12 m (39')	11 m (36')
Max Flow	5.8 L/s (92 gpm)	7 L/s (111 gpm)
Solid Passage	37 mm (1.5")	37 mm (1.5")
Diameter	243 mm (9.6")	257 mm (10.1")
Height	473 mm (18.6")	473 mm (18.6")
Weight	20 kg (44 lbs)	20 kg (44 lbs)

60Hz

	GOVOX 208	GOVOX 308
Discharge Outlet	50 mm (2")	80 mm (3")
Shaft Speed	3450 rpm	3450 rpm
Rated Output	0.75 kW (1 HP)	0.75 kW (1 HP)
Rated Head	8 m (26')	6 m (20')
Rated Flow	3 L/s (48 gpm)	4.2 L/s (66 gpm)
Max Head	12 m (39')	11 m (36')
Max Flow	5.8 L/s (92 gpm)	7 L/s (111 gpm)
Solid Passage	37 mm (1.5")	37 mm (1.5")
Diameter	243 mm (9.6")	257 mm (10.1")
Height	473 mm (18.6")	473 mm (18.6")
Weight	20 kg (44 lbs)	20 kg (44 lbs)

Download File

Brochure - Sewage Pumps	50 Hz	60 Hz
Datasheet - GOVOX 208	50 Hz	60 Hz
Datasheet - GOVOX 308	50 Hz	60 Hz

Specifications

Type	Electric Submersible Pumps
Phase	1-Phase，3-Phase
Classification	IP 68
Motor
•　Type	Induction Motor
•　Poles	2 Pole
•　Insulation	Class F
•　Protector	Circle Thermal Protector
•　Start Method	1-Phase • Capacitor-Run，3-Phase • D.O.L.
Lubricant	Food Grade (ISO VG32)
Shaft Seal
•　Type	Double Mechanical Seal
•　Desc.	Silicon Carbide VS Ceramic / Carbon
Impeller Type	Vortex
Bearings	C3 Shielded ball bearings
Cable
•　Type	PVC (CSA Certified) / H07RN-F
•　Length	6m (20') or longer upon request.
Materials
•　Pump Casing	Gray Iron
•　Impeller	Gray Iron
•　Motor Frame	Gray Iron
•　Motor Shaft	Stainless Steel
Max. Liquid Temp.	40˚C (104˚F)
Max. Sub. Depth	20m (66")
pH Range	pH 5 - pH 8
