GOMAX 75

DataSheet

50Hz
　 GOMAX 475 GOMAX 675
Discharge Outlet 100 mm (4") 150 mm (6")
Shaft Speed 1450 rpm 1450 rpm
Rated Output 7.5 kW (10 HP) 7.5 kW (10 HP)
Rated Head 16 m (52') 13.5 m (44')
Rated Flow 20 L/s (317 gpm) 33.3 L/s (528 gpm)
Max Head 26 m (85') 25 m (82')
Max Flow 40 L/s (634 gpm) 66.6 L/s (1056 gpm)
Solid Passage 76 mm (3") 76 mm (3")
Diameter 693 mm (27.3") 752 mm (29.6")
Height 838 mm (33") 838 mm (33")
Weight 142 kg (313 lbs) 148 kg (326 lbs)
60Hz
　 GOMAX 475 GOMAX 675
Discharge Outlet 100 mm (4") 150 mm (6")
Shaft Speed 1750 rpm 1750 rpm
Rated Output 7.5 kW (10 HP) 7.5 kW (10 HP)
Rated Head 16 m (52') 13.5 m (44')
Rated Flow 20 L/s (317 gpm) 33.3 L/s (528 gpm)
Max Head 26 m (85') 25 m (82')
Max Flow 40 L/s (634 gpm) 66.6 L/s (1056 gpm)
Solid Passage 76 mm (3") 76 mm (3")
Diameter 693 mm (27.3") 752 mm (29.6")
Height 838 mm (33") 838 mm (33")
Weight 142 kg (313 lbs) 148 kg (326 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOMAX 475 50 Hz 60 Hz
Datasheet - GOMAX 675 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
　•　Type Induction Motor
　•　Poles 4 Pole
　•　Insulation Class F
　•　Protector Star-Delta • Miniature Thermal Sensors， D.O.L. • Circle Therm
　•　Start Method Star-Delta，D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
　•　Type Double Mechanical Seal
　•　Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Single Channel
Bearings C3 Shielded ball bearings
Cable
　•　Type PVC (CSA Certified) / H07RN-F
　•　Length 10m (33') or longer upon request.
Materials
　•　Pump Casing Gray Iron
　•　Impeller Gray Iron
　•　Motor Frame Gray Iron
　•　Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
