DataSheet
50Hz
| GOMAX 4150 | GOMAX 6150 | |
|---|---|---|
| Discharge Outlet | 100 mm (4") | 150 mm (6") |
| Shaft Speed | 1450 rpm | 1450 rpm |
| Rated Output | 15 kW (20 HP) | 15 kW (20 HP) |
| Rated Head | 26 m (85') | 22 m (72') |
| Rated Flow | 30 L/s (475 gpm) | 41.6 L/s (660 gpm) |
| Max Head | 35 m (115') | 35 m (115') |
| Max Flow | 66.6 L/s (1056 gpm) | 86.6 L/s (1373 gpm) |
| Solid Passage | 76 mm (3") | 76 mm (3") |
| Diameter | 753 mm (29.6") | 813 mm (32") |
| Height | 830 mm (32.7") | 830 mm (32.7") |
| Weight | 178 kg (392 lbs) | 186 kg (410 lbs) |
60Hz
| GOMAX 4150 | GOMAX 6150 | |
|---|---|---|
| Discharge Outlet | 100 mm (4") | 150 mm (6") |
| Shaft Speed | 1750 rpm | 1750 rpm |
| Rated Output | 15 kW (20 HP) | 15 kW (20 HP) |
| Rated Head | 26 m (85') | 22 m (72') |
| Rated Flow | 30 L/s (475 gpm) | 41.6 L/s (660 gpm) |
| Max Head | 35 m (115') | 35 m (115') |
| Max Flow | 66.6 L/s (1056 gpm) | 86.6 L/s (1373 gpm) |
| Solid Passage | 76 mm (3") | 76 mm (3") |
| Diameter | 753 mm (29.6") | 813 mm (32") |
| Height | 830 mm (32.7") | 830 mm (32.7") |
| Weight | 178 kg (392 lbs) | 186 kg (410 lbs) |
Download File
| Brochure - Sewage Pumps | 50 Hz | 60 Hz |
| Datasheet - GOMAX 4150 | 50 Hz | 60 Hz |
| Datasheet - GOMAX 6150 | 50 Hz | 60 Hz |
Specifications
| Type | Electric Submersible Pumps |
| Phase | 3-Phase |
| Classification | IP 68 |
| Motor | |
| • Type | Induction Motor |
| • Poles | 4 Pole |
| • Insulation | Class F |
| • Protector | Star-Delta • Miniature Thermal Sensors， D.O.L. • Circle Therm |
| • Start Method | Star-Delta，D.O.L. |
| Lubricant | Food Grade (ISO VG32) |
| Shaft Seal | |
| • Type | Double Mechanical Seal |
| • Desc. | Silicon Carbide VS Ceramic / Carbon |
| Impeller Type | Single Channel |
| Bearings | C3 Shielded ball bearings |
| Cable | |
| • Type | PVC (CSA Certified) / H07RN-F |
| • Length | 10m (33') or longer upon request. |
| Materials | |
| • Pump Casing | Gray Iron |
| • Impeller | Gray Iron |
| • Motor Frame | Gray Iron |
| • Motor Shaft | Stainless Steel |
| Max. Liquid Temp. | 40˚C (104˚F) |
| Max. Sub. Depth | 20m (66") |
| pH Range | pH 5 - pH 8 |
