TANK 15

DataSheet

50Hz
　 TANK 215 TANK 315
Discharge Outlet 50 mm (2") 80 mm (3")
Shaft Speed 2850 rpm 2850 rpm
Rated Output 1.5 kW (2 HP) 1.5 kW (2 HP)
Rated Head 14 m (46') 8 m (26")
Rated Flow 4.2 L/s (66 gpm) 8.3 L/s (132 gpm)
Max Head 20 m (66') 14.5 m (48")
Max Flow 6.7 L/s (105 gpm) 11.2 L/s (177 gpm)
Solid Passage 9 mm (0.4") 9 mm (0.4")
Diameter 253 mm (10") 267 mm (10.5")
Height 568 mm (22.4") 568 mm (22.4")
Weight 33 kg (73 lbs) 33 kg (73 lbs)
60Hz
　 TANK 215 TANK 315
Discharge Outlet 50 mm (2") 80 mm (3")
Shaft Speed 3450 rpm 3450 rpm
Rated Output 1.5 kW (2 HP) 1.5 kW (2 HP)
Rated Head 14 m (46') 8 m (26')
Rated Flow 4.2 L/s (66 gpm) 8.3 L/s (132 gpm)
Max Head 21 m (69') 16 m (52")
Max Flow 6.7 L/s (105 gpm) 10.3 L/s (164 gpm)
Solid Passage 9 mm (0.4") 9 mm (0.4")
Diameter 253 mm (10") 267 mm (10.5")
Height 568 mm (22.4") 568 mm (22.4")
Weight 33 kg (73 lbs) 33 kg (73 lbs)

Download File

Brochure - Dewatering Pumps 50 Hz 60 Hz
Datasheet - TANK 215 50 Hz 60 Hz
Datasheet - TANK 315 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase，3-Phase
Classification IP 68
Motor
　•　Type Induction Motor
　•　Poles 2 Pole
　•　Insulation Class F
　•　Protector Circle Thermal Protector
　•　Start Method 1-Phase • Capacitor-Run，3-Phase • D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
　•　Type Double Mechanical Seal
　•　Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Opened
Bearings C3 Shielded ball bearings
Cable
　•　Type PVC (CSA Certified) / H07BQ-F
　•　Length 10m (33') or longer upon request.
Materials
　•　Pump Casing Gray Iron
　•　Impeller Chromium Iron
　•　Motor Frame Stainless Steel
　•　Motor Shaft Stainless Steel
　•　Strainer Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
　•　Outer Case
